前言

使用 JavaScript 实现的效果，不知道该怎么描述，给它命名为”可以拖动的百叶窗吧！“。

代码

CSS

slider.css 用于存放样式：

css

.slider {
    box-sizing: border-box;
    position: relative;
    width: 80%;
    padding-bottom: 56.25%;
    height: 0;
    margin: 0 auto;
    overflow: hidden;
    margin-top: 1em;
    margin-bottom: 1em;
}
.slider a {
    display: block;
    height: 100%;
    object-fit: cover;
    position: absolute;
    width: 100%;
    z-index: 1;
}
.mask {
    position: absolute;
    left: 49.5%; /* 初始化在中间 */
    top: 0;
    width: 1%; /* 滑块宽度 */
    height: 100%;
    background: rgba(0, 0, 0, 0.66); /* 半透明滑块 */
    cursor: ew-resize;
    z-index: 2;
}

.slider .left-image {
    clip-path: inset(0 50% 0 0); /* 初始剪裁右半部分 */
    max-width: 100%;
    display: block;
    margin: 0;
}

.slider .right-image {
    clip-path: inset(0 0 0 50%); /* 初始剪裁左半部分 */
    max-width: 100%;
    display: block;
    margin: 0;
}

JavaScript

slider.js 用于实现滑块的逻辑，把它封装起来：

javascript

class ImageSlider {
    constructor(mask, leftImage, rightImage, widthPercent) {
        this.mask = mask;
        this.leftImage = leftImage;
        this.rightImage = rightImage;
        this.isDragging = false;

        this.mask.style.left = (widthPercent - 0.5) + '%';
        this.leftImage.style.clipPath = 'inset(0 ' + (100 - widthPercent) + '% 0 0)';
        this.rightImage.style.clipPath = 'inset(0 0 0 ' + widthPercent + '%)';

        // 添加触摸事件监听器
        this.mask.addEventListener('touchstart', (e) => {
            this.isDragging = true;
            e.preventDefault(); // 阻止默认事件（如滚动）
        });
        document.addEventListener('touchend', () => {
            this.isDragging = false;
        });
        document.addEventListener('touchmove', (e) => {
            if (this.isDragging) {
                this.touchDrag(e);
            }
        });

        // 添加鼠标事件监听器
        this.mask.addEventListener('mousedown', (e) => {
            this.isDragging = true;
            e.preventDefault(); // 阻止默认事件（如选择文本）
        });
        document.addEventListener('mouseup', () => {
            this.isDragging = false;
        });
        document.addEventListener('mousemove', (e) => {
            if (this.isDragging) {
                this.drag(e);
            }
        });
    }

    // 触摸拖动事件处理函数
    touchDrag(e) {
        var rect = this.mask.parentNode.getBoundingClientRect();
        var x = e.touches[0].clientX - rect.left; // 获取触摸点相对于容器的位置
        var widthPercent = (x / rect.width) * 100;
        widthPercent = Math.min(Math.max(widthPercent, 0.5), 99.5);
        this.mask.style.left = (widthPercent - 0.5) + '%';
        this.leftImage.style.clipPath = 'inset(0 ' + (100 - widthPercent) + '% 0 0)';
        this.rightImage.style.clipPath = 'inset(0 0 0 ' + widthPercent + '%)';
    }

    // 鼠标拖动事件处理函数
    drag(e) {
        var rect = this.mask.parentNode.getBoundingClientRect();
        var x = e.clientX - rect.left; // 获取鼠标相对于容器的位置
        var widthPercent = (x / rect.width) * 100;
        widthPercent = Math.min(Math.max(widthPercent, 0.5), 99.5);
        this.mask.style.left = (widthPercent - 0.5) + '%';
        this.leftImage.style.clipPath = 'inset(0 ' + (100 - widthPercent) + '% 0 0)';
        this.rightImage.style.clipPath = 'inset(0 0 0 ' + widthPercent + '%)';
    }
}

function createImageSlider(sliderId, widthPercent=50) {
    const slider = document.getElementById(sliderId);
    const mask = slider.querySelector('.mask');
    const leftImage = slider.querySelector('.left-image');
    const rightImage = slider.querySelector('.right-image');
    return new ImageSlider(mask, leftImage, rightImage, widthPercent);
}

Html

导入 css 和 js：

html

<link rel="stylesheet" type="text/css" href="./slider.css">
<script src="./slider.js"></script>

使用这个效果：

html


<div class="slider" id="slider1">
    <img class="left-image" src="left_1.jpg" alt="jpg" />
    <img class="right-image" src="right_1.jpg" alt="jpg" />
    <div class="mask"></div>
</div>

<script>createImageSlider('slider1', 67.5);</script>

...

<div class="slider" id="slidern">
    <img class="left-image" src="left_n.jpg" alt="jpg" />
    <img class="right-image" src="right_n.jpg" alt="jpg" />
    <div class="mask"></div>
</div>

<script>createImageSlider('slidern', 48.5);</script>

演示

拿出珍藏私货！
